The production line includes the feeder, the medium frequency induction furnace, skew rolling mill, quenching machine and so on.
　　　
Skew rolling mill is the special equipment which applies the Spiral groove skew rolling forming process to manufacture milling steel ball, bearing ball blanks and other metal ball. This skew rolling mill applies the semi closing frame so it is easy to change the roller. The skew rolling mill have the complete adjusting function; The rigidity of machine base is good; The manufactured products have the high accuracy. The whole machine includes major motor, speed reducer, universal-joint spindle and the working main machine.

The skew rolling forming process is a new technology to produce the rotary parts or blanks. It can be used to manufacture the milling steel ball, bearing ball, auto part and other products.

Advantages:

1. Greatly improve the productivity;

2. Highly reduce the cost;

3. Improve quality and the working condition and so on.



•
•
•
•
  120mm skew rolling mill running in Armenia produce grinding balls
•
  40mm grinding steel ball skew rolling mill production line in Turkey
•
  steel ball rolling mill

•
  100mm Grinding steel ball skew rolling mill working in Ghana
•
  120mm Grinding steel ball skew rolling machine production line in Indonesia
•
  60mm Hot-rolled grinding media balls machine skew rolling production line in Romania
•
  50mm Grinding ball forming machine rolling production line in Vietnam
•
  60mm skew rolling machine in customer
•
  120mm Hot-rolled skew rolling miller for grinding steel ball production line in Armania
